    Hanging System Operable Movable Partition Walls MDF + Aluminum Material

    Ask Lasest Price
    Brand Name : BUNGE
    Model Number : Series 65 mm movable partition walls
    Certification : ISO9001
    Price : 75 / 108 dollars per square meter
    Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 5000 squaremeters per month
    Delivery Time : Shipped in 10 days after payment, based on the quantity
    • Product Details
    • Company Profile

    Hanging System Operable Movable Partition Walls MDF + Aluminum Material

    Banquet Hall High Quality Hanging System Operable Movable Partition Walls


    Specification:

    There are wide of range face finishes are available :melamine faced MDF or Plywood,,fabric,carpet,fabric,artificial,leather,wood veneer,high pressure laminate,Formica ,acoustic panel,white boad ect.,panels may also be supplied unfinished for field decoration,Standard frame color is clear anodized aluminum,custom powder coating colors are available.

    BUNGE works with Architects,designer,developers,contractores and owners in design product selection,decorative finishes,project management and after-sales warranty services as her one-stop solution business service.

    Hanging System Operable Movable Partition Walls MDF + Aluminum Material

    Bunge Operable Wall Systems-Technical Information

    TYPEBG65BG85BG100 & BG125
    Panel suspensionTop hung only
    Track systemSingle or twin point
    Panel thickness65 mm85 mm100 mm
    Panel heightUp to 4000mm,heights greater than 3000mm refer to our technical dept.Up to 6000mm, heights greater than 6000mm refer to our technical dept. Inset passing doors above 2400mm. Full height passing door up to 3000mm high document ‘M’ disabled doors optional.
    Max height4000mm6000mm18000mm
    Panel width

    500 - 1200mm

    1' 5/8" -- 4'

    500 - 1200mm

    1' 5/8" -- 4'

    500 - 1200mm

    1' 5/8" -- 4'

    FrameAluminumAluminumAluminum
    Surface material9mm9mm12mm
    Fire safetyOptional class IOptional class IOptional class I
    Vertical profilesAluminum, anodized with sealing profiles, painter optionalAluminum, anodized with sealing profiles, painter optionalAluminum, anodized with sealing profiles, painter optional
    Retractable sealsAluminum, black with double rubber sealsAluminum, black with double rubber sealsAluminum, black with double rubber seals
    Operation of sealsManual, with supplied operating handle
    LockingOptional lock to passing doors
    Passing doorsSingle open in one panel or double open in two panel
    Sound insulation32-38dB Rw36-45dB Rw42-55dB Rw
    WeightApprox 22-35kg/sq MApprox 25-40kg/sq MApprox 30-48kg/sq M


    2,FIXING

    Moveable partitions are a series of individually operated panels along a track system designed for maximum space planning flexibility. They can be arranged quickly, easily and efficiently.Movable partition wall is also called sliding partition wall or movable sound insulation wall, which is widely used to divide big room into small rooms. Each piece of partition can turn 360 degree which makes it flexible. Different core materials decide its sound insulation performance and various finishes make it adapt to many projects such as hotel, exhibition hall, restaurant, multi-functional room, etc.

    Hanging System Operable Movable Partition Walls MDF + Aluminum Material


    Common Applications:

    1.studios, recording rooms, listening rooms, rehearsal rooms and more professinally interspace timbre projects.

    2.theaters, indoor gymnasiums, discos, KTV rooms and more performance and entertainment location.

    3.meeting rooms, offices, halls, hotels and more sound absorption and secrecy projects.

    4.air-port, railways, bus-stops, manufactories, workshops and more noise reduction projects.

    Hanging System Operable Movable Partition Walls MDF + Aluminum Material
